YC-SM10P

Flush Mount 10.1 inch Smart Home Android POE Touch Control Panel

Key Features:

POE (Power Over Ethernet) power supply for simplified installation.
Universal bracket compatible with various wall boxes, ensuring easy setup.
Available in both silver and classic black to match any decor.
Google Play Store for all your app needs.
Customization options available for OEM, including logo personalization and model number changes.

SM10P is a model we are using to focus on the high-end market. Each metal case is made by CNC, which can offer a sleek and modern look, especially if the finish has a brushed or polished texture.

Send Inquiry

Overview

YC-SM10P – 10-Inch Smart Touch Control Panel for Seamless Automation

The YC-SM10P is a 10-inch smart touch control panel designed for smart homes, offices, and meeting rooms, offering an intuitive interface to control various smart devices. Powered by the RK3566 Quad-Core ARM Cortex-A55 processor and running Android 11, this panel ensures fast, responsive, and efficient operation for modern automation needs.

High-Performance Touchscreen & Display

✅ 10-inch IPS capacitive touchscreen, supporting 10-point multi-touch for smooth and precise control
✅ 1280×800 high-resolution display, delivering crisp and vibrant visuals
✅ 500 Nits brightness, ensuring excellent visibility in different lighting conditions
✅ Seamless fingertip interaction, with smooth gestures including swipe left/right, zoom in/out, slide up/down

Reliable Hardware & Connectivity Options

✅ 2GB RAM + 32GB ROM, providing ample storage and smooth performance
✅ Wi-Fi support, ensuring flexible wireless connectivity
✅ Bluetooth 4.0, allowing seamless pairing with smart devices
✅ RJ45 Ethernet with PoE (Power over Ethernet) support, compliant with IEEE 802.3 at/af standards, allowing both power and data transmission through a single cable

Versatile Smart Control Hub

With the YC-SM10P, users can centralize control over multiple smart devices:
✅ Lighting Control – Easily turn lights on/off and adjust brightness
✅ Climate Management – Control air conditioning and heating systems
✅ Curtain Automation – Open or close curtains with a touch
✅ Security Management – Integrate with smart door locks and access control systems
✅ Smart Office & Meeting Room Automation – Enhance office efficiency with centralized control
✅ App Compatibility – Fully supports mobile app control for remote access

Flexible Installation & Wide Application

✅ Supports embedded wall mounting, ensuring a clean and professional setup
✅ Compatible with three types of wall switch boxes, including 86-type wall boxes, making installation easy across different environments
✅ Ideal for smart homes, meeting rooms, offices, and hospitality applications

Portworld offers wholesale and customizable solutions, providing tailored hardware and software services to meet various automation needs.

Specification

System	CPU	RK3566 Quad-core ARM Cortex-A55,up to 1.8GHz
	RAM	2GB/4GB
	ROM	32GB
	System	Android 11
Touch Panel	Display size	10″ IPS screen
	Resolution	1280*800
	Touch Panel	10 points capactive touch panel,IPS
	Brightness	500Nits
	Screen Ratio	16:09
	Display Area	218*135mm
Network	WIFI	2.4G/5G WiFi
	Bluetooth	BlE 5.2
	Ethernet	10M/100M
Interface	RJ45	Ethernet interface input(RJ45 cable),Support POE
	Type C	Type C*1
	Reset	1*Reset hole
	Restart	1*Restart hole
	DC	DC 12V/24V input
	RS485	RS485
Media plays	Camera	No Camera
	Speaker	Speaker*1W
	Video	MOV 1080P/AVI/WMV/RM/RMVB/3GP/MKV/MP4/ASF/VOB
	Audio	MP3/WMA/WAV/AAC/FLAC/OGG
	Entertainment	Video/Movie/Music/FM online
Others	Speaker	2W*2pcs
	Installation	In wall,suitable for EU/US/86 Type wall box
	Working temperature	-5℃-70℃
	color	Silver
	language	Support Multi-language
Warranty	12 months

Q&A

Q1:Does your panels support Zigbee?

A1:If you need your panels to work with Zigbee, we suggest using a Gateway. Connecting all sensors to the gateway, which is then linked to our control panel. A demonstration video illustrating this process can be found at the following link: https://youtu.be/D4vSVo23JXg

Q2:Does your panels support KNX?

A2:We are not currently a member of KNX, so we do not have authorization to include KNX protocol in our standard models. However, we offer two solutions:

1. Custom Integration: With 18 years of R&D and manufacturing experience, we can integrate KNX modules into our mainboards. We will provide a neutral Android OS, and you can handle the KNX firmware. This option allows you to create a custom model tailored to your specifications.

2. KNX IP Gateway Solution: For a quick and straightforward setup, you can use a KNX IP gateway to bridge your devices with our panel.

Q3:Can I open the box and start using the panel?

A3:All of our panels run on a neutral Android OS. They can connect wirelessly via Wi-Fi and Bluetooth. For wired connections, we offer RS485. Each panel comes with the Google Play Store, allowing you to easily install apps like Tuya and Home Assistant. Additionally, we can assist with pre-installing your APK upon request.

Q4:Does it come with POE?

A4:Yes, all our smart home control panels support PoE, adheres to the IEEE802.3af standard

Q5:What operating systems do you supply?

A5:Our smart home solutions support a variety of operating systems, including Android and Linux-based systems such as Ubuntu, Debian, and Buildroot.
