YC-SM08P 8” POE Smart Home Touch Control Panel

YC-SM08P

8″ Android 11 POE Smart Home Touch Control Panel

Key Features

CPU: RK3566 Quad-core cortex-A55, 1.8Ghz
Memory: RAM 2GB/4GB, ROM 16GB/32GB
Operation system: Android 11
Comes with POE RJ45 port, DC port, Type C port, TF card slot, RS485 serial port
Widely used for smart home control system/smart hotel system/room controller/smart kitchen etc.
Support different wall switch box installation: 86 type wall box, US type wall box and EU type wall box

The 8″ model SM08P Smart Home Control Panel comes equipped with 2 side LED bar, for which we can provide the API for development. If you possess software development skills and have your own APK, the LED can serve as a useful feature in various scenarios, such as meeting booking or smart home applications.

Send Inquiry

Overview

Specification

Q&A

Tutorial

Overview

YC-SM08P – 8-Inch Smart Touch Control Panel for Intelligent Automation

The YC-SM08P is an 8-inch smart touch control panel designed to provide seamless automation for smart homes, hotels, and office environments. Equipped with a high-performance RK3566 Quad-Core Cortex-A55 processor and running on Android 11, this device delivers a fast and stable user experience.

Vibrant Display & Intuitive Touchscreen

8-inch IPS touchscreen with 5-point capacitive touch, offering a smooth and highly responsive control experience
800×1280 resolution ensures sharp and vivid visuals
300cd/m² brightness, providing clear visibility in various lighting conditions
Optional RGB LED lights on both sides, adding aesthetic appeal and visual alerts

Robust Hardware & Multiple Connectivity Options

2GB RAM + 16GB ROM, ensuring efficient performance for multitasking
Built-in RJ45 Ethernet port with PoE (Power over Ethernet) support (IEEE 802.3 at/af), simplifying installation with power and data transmission over a single cable
Supports 802.11b/g/n Wi-Fi (optional 5G Wi-Fi) for flexible wireless connectivity
Integrated Bluetooth 4.0, allowing seamless pairing with smart devices
Built-in RS485 port, enabling direct connection to RS485-compatible devices for advanced automation

All-in-One Smart Control Solution

The YC-SM08P serves as a centralized smart control hub, allowing users to efficiently manage various smart devices, including:
Lighting Control – Adjust brightness and turn lights on/off effortlessly
Curtain Automation – Set automatic schedules for opening and closing curtains
Temperature Control – Manage air conditioning and heating systems with ease
Smart Door Locks – Enhance security with remote access management
Meeting Room & Office Automation – Improve efficiency by integrating with conference room systems
App Control – Seamless compatibility with mobile applications for remote operation

Versatile Installation & Application

Designed for easy wall mounting, the YC-SM08P supports three types of wall boxes, including 86-type wall boxes, ensuring compatibility with different installation environments. It is ideal for smart homes, hotels, offices, and commercial automation projects.

Portworld offers wholesale and custom solutions, providing tailored hardware and software services to meet the specific needs of different automation applications.

Portworld’s Services

Portworld (Sunworld) Technology Co., Ltd is a leading provider of touch system solutions, specializing in the R&D and production of smart home tablets, PoE industrial embedded touch panels, digital signage, and touch monitors. With 18 years of R&D experience, we offer OEM/ODM customization services to meet the diverse needs of our clients.

OEM/ODM Customization Services

Portworld offers comprehensive OEM/ODM solutions, allowing brands to develop customized smart control panels and touch devices that stand out in the market.

Appearance Customization: Supports size, material, casing design, and color customization to align with brand identity.
Hardware Customization: Provides PCBA design, interface configuration, camera, microphone, and speaker integration.
Software Customization: Supports Android, Linux (Ubuntu/Debian), and Windows OS customization with full SDK/BSP development support.
Branding Customization: Offers logo printing, UI design, and packaging customization for enhanced brand recognition.

Smart Home Control Panel Solutions

Portworld manufactures smart home control panels in 4-inch, 5-inch, and various other sizes, suitable for homes, hotels, office buildings, and commercial automation.

Multi-OS Compatibility: Supports Android, Linux (Ubuntu/Debian), and Windows.
Multiple Processor Options: Features Rockchip, MTK, Intel, AMD, Snapdragon, and Spreadtrum chipsets for different performance needs.
Multiple Control Methods: Supports touchscreen control, mobile app remote control, and voice control (Google Assistant, Alexa).
Smart Device Integration: Connects seamlessly with smart lighting, motorized curtains, security cameras, HVAC systems, and access control.

Specification

System	CPU	RK3566 Quad-core ARM Cortex-A55,up to 1.8GHz
	RAM	2GB
	ROM	16GB
	System	Android 11
Touch Panel	Display size	8 inch
	Resolution	800*1280 IPS
	Touch Panel	5 points capactive touch panel,IPS
	Brightness	300Nits
Network	WIFI	802.11b/g/n(5G WIFi optional)
	Bluetooth	Bluetooth 4.0
	Ethernet	10M/100M
Material	Plastic case +Glass touch panel	Plastic case cover
Interface	RJ45	Ethernet interface input(RJ45 cable),support POE 48V 2A
	Type C	Type C*1
	TF Card slot	TF Card*1
	Restart	Built-in
	power supply	DC 12V/24V input
	RS485	RS485 A,B
Media plays	Camera	No Camera
	Speaker	Speaker*1W
	Video	MOV 1080P/AVI/WMV/RM/RMVB/3GP/MKV/MP4/ASF/VOB
	Audio	MP3/WMA/WAV/AAC/FLAC/OGG
	Entertainment	Video/Movie/Music/FM online
Others	Battery	No
	Mount	In wall
	Power consumption	2*10W MAX
	Working temperature	-5℃-70℃
	color	Silver/Black
	language	Multi language

Q&A

Q1:Does your panels support Zigbee?

A1:If you need your panels to work with Zigbee, we suggest using a Gateway. Connecting all sensors to the gateway, which is then linked to our control panel. A demonstration video illustrating this process can be found at the following link: https://youtu.be/D4vSVo23JXg

Q2:Does your panels support KNX?

A2:We are not currently a member of KNX, so we do not have authorization to include KNX protocol in our standard models. However, we offer two solutions:

1. Custom Integration: With 18 years of R&D and manufacturing experience, we can integrate KNX modules into our mainboards. We will provide a neutral Android OS, and you can handle the KNX firmware. This option allows you to create a custom model tailored to your specifications.

2. KNX IP Gateway Solution: For a quick and straightforward setup, you can use a KNX IP gateway to bridge your devices with our panel.

Q3:Can I open the box and start using the panel?

A3:All of our panels run on a neutral Android OS. They can connect wirelessly via Wi-Fi and Bluetooth. For wired connections, we offer RS485. Each panel comes with the Google Play Store, allowing you to easily install apps like Tuya and Home Assistant. Additionally, we can assist with pre-installing your APK upon request.

Q4:Does it come with POE?

A4:Yes, all our smart home control panels support PoE, adheres to the IEEE802.3af standard

Q5:What operating systems do you supply?

A5:Our smart home solutions support a variety of operating systems, including Android and Linux-based systems such as Ubuntu, Debian, and Buildroot.
